HNSC-A product description

Properties

Inclination switches from the HNSC-A series are based on a mechatronic inclination element and are therefore particularly insensitive to vibrations and shocks.

  • Inclination monitoring of one axis.
  • Simple mounting and commissioning.
  • Available for AC and DC supply voltage.

For application examples of the individual products, open the menu below.

HNSC-A-...-DC / Power supply 9 - 30 VDC

HNSC-A-UNs-DC

HNSC-A-UNs-DC

One-sided monitoring of the X-axis, switching angle of 10° inclination. Version as normally closed contact.
Suitable for applications with medium accuracy requirements.
Bild LMs-DC

HNSC-A-LMs-DC

Symmetrical monitoring of the X-axis on both sides, switching angle 10° inclination. Version as normally closed contact.
Suitable for applications with medium accuracy requirements.

HNSC-A-...-AC / Power suply 42 - 250 VAC

Bild HNSC-A-15-GR-AC-0,5AC

HNSC-A-15-GR-AC-0.5A

Switchter for round mounting with approx. 10° hysteresis. Suitable for simple, cost-sensitive applications with low accuracy requirements. Version as normally closed contact.
Exif_JPEG_420

HNSC-A-15-GP-AC-0.5A

Switches at 15° inclination. Suitable for cost-sensitive simple applications with low accuracy requirements
for one-sided monitoring of the X-axis. Version as normally closed contact.
HNSC-A-03-HS-AC-Bild-scaled-not_available

HNSC-A-03-HS-AC

Switch with switching angle of 3° inclination. For one-sided monitoring of the X-axis.
Suitable for applications with higher accuracy requirements and low hysteresis. Version as normally closed contact.
